Outdoor Power Vented Duct Furnace (Model HFP)

These heaters have input ranges from 75,000 to 400,000 Btu/Hr and can operate on either natural or propane gas. The airflow direction can be specified when ordering the unit. The duct furnace is certified for location either upstream or downstream from cooling coils and has holes to drain any condensate that may form onto the roof.

Standard Features:

  • C.S.A. certification – bearing C.S.A. logos
  • ETL certification
  • All units a minimum of 80% thermal efficient
  • 18-gauge aluminized steel cabinet with a baked-on polyester powder paint finish on exterior casing parts
  • Certified to 3.0″ W.C. external static pressure

Optional Features:

  • 409 stainless steel heat exchanger and burner
  • 409 stainless steel drip pan
  • Two-stage, mechanical modulation, and electronic modulation controls for either natural or propane gas
  • Building management compatible gas controls for modulation control using 0 – 10 Vdc or 4 – 20 mA input
  • High and/or low gas pressure switches
